Engine Repair Shop

DYESS AIR FORCE BASE, Texas -- Airman 1st Class Katherine Leas loosens engine hardware for fan disassembly and maintenance, Mar. 24. The loosened hardware keeps the fan casing in place in front of the engine blades to allow the fan to work properly. (U.S. Air Force Photo by Airman 1st Class Micheal Breaux)

Photo Details / Download Hi-Res
Engine Repair Shop

DYESS AIR FORCE BASE, Texas -- Airman 1st Class Katherine Leas loosens hardware on a B-1 engine during routine maintenance at the engine test center, Mar. 24. The bolts hold the fan casing group together to allow the fan blades to rotate properly. (U.S. Air Force Photo by Airman 1st Class Micheal Breaux)

Photo Details / Download Hi-Res
Engine Repair Shop

DYESS AIR FORCE BASE, Texas -- Airman 1st Class A.J. Carden turns a PTO wrench to spin the turbines and allow the borescope to view the engine, Mar. 24. The PTO wrench determines the speed of the turbines and allows the user of the borescope to properly inspect the engine. (U.S. Air Force Photo by Airman 1st Class Micheal Breaux)

Photo Details / Download Hi-Res
Engine Repair Shop

DYESS AIR FORCE BASE, Texas -- Senior Airman Jack Ruen runs a borescope into the engine turbines, Mar. 24. The borescope monitors the turbines for small cracks and potential damage that may cause engine failure. (U.S. Air Force Photo by Airman 1st Class Micheal Breaux)

Photo Details / Download Hi-Res
Engine Repair Shop

DYESS AIR FORCE BASE, Texas -- Airman 1st Class Katherine Leas looks in her toolbox for a wrench to take apart a B-1 engine, Mar. 24. The engine disassembly is necessary to find parts that need routine maintenance. (U.S. Air Force Photo by Airman 1st Class Micheal Breaux)

Photo Details / Download Hi-Res
Engine Repair Shop

DYESS AIR FORCE BASE, Texas -- Airman 1st Class A.J. Carden uses a AFTO form 350 to identify an Anti-Ice Manifold during an engine disassembly, Mar. 24. The process of using a AFTO form 350 is also known as tagging parts and is primarily used to identify different parts of a unassembled engine. (U.S. Air Force Photo by Airman 1st Class Micheal Breaux)

Photo Details / Download Hi-Res
Engine Repair Shop

DYESS AIR FORCE BASE, Texas -- Senior Airman Jack Ruen watches a monitor that is connected to a borescope inside of a B-1 engine, Mar. 24. The Borescope is a cable fed camera that is directed into the turbines of an engine and allows the user to view the turbines on a monitor display. (U.S. Air Force Photo by Airman 1st Class Micheal Breaux)

Photo Details / Download Hi-Res
Engine Repair Shop

DYESS AIR FORCE BASE, Texas -- Staff Sergeant Jerusha Johnson loosens nuts on a B-1 engine during an engine disassembly at the engine test center Mar. 24. The bolts hold the outer part of the fan together to allow the engines fan blades to rotate properly. (U.S. Air Force Photo by Airman 1st Class Micheal Breaux)

Photo Details / Download Hi-Res

Engine repair

Published March 25, 2008
